PARTS & DRAWINGS

32mm Step-Cast Part Information

New for 2025:

New CSU	New CSU lighter than before, where stanchions are pressed at an angle to achieve offset
New Lower Assembly	Reversed arch with a radical design to reduce weight and increase torsional stiffness. No groove upper bushings improving ride quality. Not backwards compatible.
New Grip SL Damper	Grip SL damper is extremely lightweight with no compromise to performance. Replaces FIT4 and utilizes wrench flats.
New Grip Damper	Now using 4wt. oil. No other changes at this travel.
New Kabolt SL Axle	Lighter than previous Kabolt Axle, only offered in 15 x 110 sizing.
New Air Shaft Assembly	Now utilizing the cassette tool to remove air cap. NA2 design configured to the new 32 SC chassis.
New Decals	New Sag/Air/Rebound Chart for Grip SL damper as well as Kashima/Grey decals for F-S shiny black fork. P-S decal kits are unchanged

Maintenance Information:

Service Interval	Full Service 125 Hours
803-00-944	Kit: Dust Wiper, Forx, 32mm, Low Friction, No Flange
803-01-320	Seal Kit: MY19+ 32, 34, 36, 38, 40 GRIP Cartridge Rebuild
803-04-090	Seal Kit: 2025 Grip SL (32 TC, 32 SC, 34 SC)
803-00-962	Seal Kit: 32 FLOAT NA2 Rebuild
803-04-050	Kit: 2025, 32/32 SC, Lower Leg Bushings
398-00-681	32 Damper-side and ALL 32-34-36-38-40 Spring-side Removal Tool
398-00-770	Tooling: Guided Fork Seal Driver, One Piece Seal/Wiper, 32
803-01-324	Kit: Tooling: 2019 Clamps, Grip Damper, Body and Shaft
398-00-763	Tooling: DPX2, Base Valve Driver

Air Spring Tuning Information:

803-01-666	Kit: Volume Spacer, FLOAT NA 2, 32, Quantity 5, (Ref: 234-04-811)
234-04-811	Volume Spacer, FLOAT NA 2, 32

Oil Information:

Application	Description	Part #
All Grip SL and GRIP Dampers and Damper Bath Oil	Oil: Suspension Fluid, 4 WT, 1.0 Liter Bottle	025-03-063
All Grip SL and GRIP Dampers and Damper Bath Oil	Oil: Suspension Fluid, 4 WT, 23L	025-03-064
FLOAT NA2 Air Chamber and Bath Oil	Oil: AM, FOX 20 WT Gold, T22238, 32 oz	025-03-072
FLOAT NA2 Air Chamber and Bath Oil	Oil: AM, FOX 20 WT Gold, T22238, 23L	025-03-073

Oil Application	Oil Volume
Grip SL Damper Side Bath	15cc (FOX 4 WT)
GRIP Damper Side Bath	40cc (FOX 4 WT)
Air Side Bath	10cc (FOX 20 WT Gold)
Air Chamber	3cc Slickoleum (Slick Honey)/3cc (FOX 20 WT Gold)

CSU Assemblies:

820-12-768-KIT	Service Set: 2025 32 29in 80-100 SC Kashima Fox Shiny Black Alum Zero OS (44 Rake) 1.5 Taper CSU
820-12-772-KIT	Service Set: 2025 32 29in 80-100 SC Black Ano Fox Matte Black Alum Zero OS (44 Rake) 1.5 Taper CSU

Lower Leg Assemblies:

820-20-282-KIT	Service Set: 2025 32 29in 80-100 SC 15x110 LW Black Kabolt, Fox Matte Black Lower Leg Assy
820-20-284-KIT	Service Set: 2025 32 29in 80-100 SC 15x110 LW Black Kabolt, Fox Shiny Black Lower Leg Assy
820-20-285-KIT	Service Set: 2025 32 29in 80-100 SC 15x110 LW Black Kabolt, Fox Shiny Orange Lower Leg Assy
820-20-407-KIT	Service Set: 2025 32 29in 80-100 SC 15x110 LW Black Kabolt, Podium Gold Lower Leg Assy

Axle Assemblies:

229-19-561

Shaft: Axle, 15 X 110mm Kabolt SL, Small Flange, Black Ano (T)

Lower Leg Small Parts:

820-09-085-KIT

Service Set: 2022 32 TC Disc Brake Hose Guide Parts

Decal Kits:

803-04-061	Decal Kit: 2025, 32 SC, F-S, Kashima/Grey Logo, Shiny Black Fork
803-04-062	Decal Kit: 2025, 32 SC, F-S, Black Logo, Shiny Orange Fork
803-04-063	Decal Kit: 2025, 32 SC, F-S, Black Logo, Podium Gold Fork
803-04-064	Decal Kit: 2025, 32 SC, P-SE, Gray Logo, Shiny Black Fork
803-04-065	Decal Kit: 2025, 32 SC, P-S, Gray Logo, Matte Black Fork

Complete Cartridges:

820-18-503-KIT	Service Set: 2025 32 SC 100, GRIP SL, 3 Pos Adj, Cart Assy Complete
820-18-511-KIT	Service Set: 2025 32 SC 100, GRIP SL, Push-Lock Remote Cart Assy Complete
820-18-514-KIT	Service Set: 2025 32 SC 100, GRIP SL, PTU Remote Cart Assy Complete
820-18-556-KIT	Service Set: 2025 32 29in SC 80-100, Grip Cart Assy Complete
820-18-563-KIT	Service Set: 2025 32 29in SC 80-100, Grip Push-Lock Remote Cart Assy Complete

Cartridge Topcap Assemblies:

820-05-730-KIT	Service Set: 2025 32 SC, GRIP SL, Topcap Assy, 3 Pos Adj
820-05-740-KIT	Service Set: 2025 32 SC, GRIP SL, Remote, Topcap Assy
820-05-522-KIT	Service Set: 2019 32 SC, Grip, Topcap Assy
820-05-604-KIT	Service Set: 2020 32 SC, Grip Remote, Topcap Assy, Interface Parts not Included

Damper Topcap Interface Parts:

820-05-731-KIT	Service Set: 2025 GRIP-SL Topcap Interface Parts, Blue Ano
820-05-767-KIT	Service Set: 2025 GRIP-SL Topcap Interface Parts, Black Ano
820-05-757-KIT	Service Set: 2025 Grip SL Push-Lock Remote, Topcap Interface Parts
820-05-758-KIT	Service Set: 2025 Grip SL PTU Remote, Topcap Interface Parts
820-05-460-KIT	Service Set: 2018 Grip P-S 32 Topcap Interface Parts
820-05-611-KIT	Service Set: 2020 Grip Push-Lock Remote, Topcap Interface Parts

Remotes and Accessories:

820-07-190	Remote Assembly, 2022 Suspension Remote, 3-POS, 22.2, Dual 0,9mm Cable
820-07-191	Remote Assembly, 2022 Suspension Remote, 2-POS, 22.2, Dual 0,9mm Cable
820-07-129-KIT	Service Set: 2022 I-SPEC-EV Remote Adaptor Assembly for 2022 Forks/Shock Remotes
825-05-006-KIT	Service Set: 22.2 Remote Band Clamp Assy, For: 2022 Fork/Shock Remotes and 2021 1x Transfer Remotes

Damper Bottom Stud Interface Parts:

820-05-734-KIT	Service Set: 2025 GRIP SL Bottom Stud Interface Parts
820-05-705-KIT	Service Set: 2022 34SC Bottom Stud Interface Parts, All Dampers

Damper Shaft Assemblies:

820-05-733-KIT	Service Set: 2025 32 SC 100, GRIP SL LSR Damper Shaft Assy
820-03-587-KIT	Service Set: 2019 32 Grip SC Damper Shaft Assy

FLOAT NA2 Air Shaft Assemblies:

820-02-670-KIT

Service Set: Air Shaft Assy, 2025, 32 SC, 100mm, FLOAT LC NA 2, 1.132 Bore, Al NP

FLOAT NA2 Topcap Assemblies:

820-05-752-KIT	Service Set: Topcap Assy, 2025, FLOAT LC NA 2, 32, Black, SC, Internal Spline
234-44-360	Air Knob, 2025 32SC Fork, Black Ano
234-44-361	Air Knob, 2025 32SC Fork, Blue Ano
